Collar Button

The Collar Button Ventilation Tube is symmetrical in design with an outer flange for additional security to prevent premature extrusion.

EnquireCatalogueTraining

Overview

The Adept Medical Collar Button Ventilation Tube has an outer flange, providing additional security and preventing premature extrusion. Available with two different sized internal diameters, offering an enhanced through-lumen view.

Available in a blue variant for optimal tube distinction and visibility in the ear canal.

The Tail variant is offered to provide ease of engagement with forceps, facilitating tube insertion and removal.

-Supplied sterile, by EtO gas.

-Available in 10 packs of singles or doubles.

-Moulded from fluoroplastic, ensuring biocompatibility and compliance with ISO 10993, as well a smooth texture to aid in insertion.

-Single-use product supplied in an ergonomic case.

-Recommended to be inserted using instruments found in the Adept Medical Myringotomy Kit range.

Applications

No items found.

Highlights

Collar Button
Collar Button
Collar Button

Features

No items found.

Specifications

Product Variants & Specifications

Collar Button (1.14mm)

+
No items found.

Product Code: NZ3211 (Single) | NZ3211-2 (Double)

Quantity: Single/10 Pack | Double/10 Pack

Sterility: Yes, by EtO gas

Material: Fluoroplastic

Internal Diameter (mm): 1.14

Inner Flange Diameter (mm): 1.55

Outer Flange Diameter (mm): 2.6

Inter Flange Distance (mm): 1.11

Length (mm): 1.71

Collar Button (1.14mm)

Product Code: NZ3211 (Single) | NZ3211-2 (Double)

Quantity: Single/10 Pack | Double/10 Pack

Sterility: Yes, by EtO gas

Material: Fluoroplastic

Internal Diameter (mm): 1.14

Inner Flange Diameter (mm): 1.55

Outer Flange Diameter (mm): 2.6

Inter Flange Distance (mm): 1.11

Length (mm): 1.71

Collar Button (1.14mm) - Blue

+
No items found.

Product Code: NZ3211Blue (Single) | NZ3211Blue-2 (Double)

Quantity: Single/10 Pack | Double/10 Pack

Sterility: Yes, by EtO gas

Material: Fluoroplastic

Internal Diameter (mm): 1.14

Inner Flange Diameter (mm): 1.55

Outer Flange Diameter (mm): 2.6

Inter Flange Distance (mm): 1.11

Length (mm): 1.71

Collar Button (1.14mm) - Blue

Product Code: NZ3211Blue (Single) | NZ3211Blue-2 (Double)

Quantity: Single/10 Pack | Double/10 Pack

Sterility: Yes, by EtO gas

Material: Fluoroplastic

Internal Diameter (mm): 1.14

Inner Flange Diameter (mm): 1.55

Outer Flange Diameter (mm): 2.6

Inter Flange Distance (mm): 1.11

Length (mm): 1.71

Collar Button (1.14mm) - With Tail

+
No items found.

Product Code: NZ3212 (Single) | NZ3212-2 (Double)

Quantity: Single/10 Pack | Double/10 Pack

Sterility: Yes, by EtO gas

Material: Fluoroplastic

Internal Diameter (mm): 1.14

Inner Flange Diameter (mm): 1.55

Outer Flange Diameter (mm): 2.6

Inter Flange Distance (mm): 1.11

Length (mm): 1.71

Tail (mm): 3.1

Collar Button (1.14mm) - With Tail

Product Code: NZ3212 (Single) | NZ3212-2 (Double)

Quantity: Single/10 Pack | Double/10 Pack

Sterility: Yes, by EtO gas

Material: Fluoroplastic

Internal Diameter (mm): 1.14

Inner Flange Diameter (mm): 1.55

Outer Flange Diameter (mm): 2.6

Inter Flange Distance (mm): 1.11

Length (mm): 1.71

Tail (mm): 3.1

Collar Button (1.27mm)

+
No items found.

Product Code: NZ3111 (Single) | NZ3111-2 (Double)

Quantity: Single/10 Pack | Double/10 Pack

Sterility: Yes, by EtO gas

Material: Fluoroplastic

Internal Diameter (mm): 1.27

Inner Flange Diameter (mm): 1.67

Outer Flange Diameter (mm): 3

Inter Flange Distance (mm): 1.62

Length (mm): 2.22

Collar Button (1.27mm)

Product Code: NZ3111 (Single) | NZ3111-2 (Double)

Quantity: Single/10 Pack | Double/10 Pack

Sterility: Yes, by EtO gas

Material: Fluoroplastic

Internal Diameter (mm): 1.27

Inner Flange Diameter (mm): 1.67

Outer Flange Diameter (mm): 3

Inter Flange Distance (mm): 1.62

Length (mm): 2.22

Collar Button (1.27mm) - With Tail

+
No items found.

Product Code: NZ3112 (Single) | NZ3112-2 (Double)

Quantity: Single/10 Pack | Double/10 Pack

Sterility: Yes, by EtO gas

Material: Fluoroplastic

Internal Diameter (mm): 1.27

Inner Flange Diameter (mm): 1.67

Outer Flange Diameter (mm): 3

Inter Flange Distance (mm): 1.62

Length (mm): 2.22

Tail (mm): 3

Collar Button (1.27mm) - With Tail

Product Code: NZ3112 (Single) | NZ3112-2 (Double)

Quantity: Single/10 Pack | Double/10 Pack

Sterility: Yes, by EtO gas

Material: Fluoroplastic

Internal Diameter (mm): 1.27

Inner Flange Diameter (mm): 1.67

Outer Flange Diameter (mm): 3

Inter Flange Distance (mm): 1.62

Length (mm): 2.22

Tail (mm): 3
